Blackview B/U Battery

Specifications

Model Name: B-112
LED: Charging state: (RED = charging, GREEN = fully charged). Battery meter (white LEDs).
Operating Temperature: Charging Temperature: 0°C-45°C
Discharging Temperature: -20°C-60°C
Storage Temperature: -20°C-60°C
Color/Size/Weight: Black / 128 mm (W)x102 mm (L)x50 mm (H) / 550 g
Quiescent Current: 12.8 V / 5 mA
Capacity: 12.8 V / 3000 mAh / 38.4 W
Hours of Use: Approx. 12 hours | 12 V / 3.4 Wh power consumption 1CH Dashcam
Charging Time: Lighter plug: Approx. 1 hour
Input Voltage/Current: MIN: 12 V / 6.5 A, MAX: 24 V / 3.65 A
Input Power: Lighter plug: 12 V?24 V / 6.5 A (max)
Charged Voltage / Current: 14.6 V / 3.5 A
USB Power Output: MIN: 5 V / 100 mA
Output Voltage: When charging from a 12 V cigarette lighter socket:
- 2 USB sockets: each 5 V / 2 A
- Dashcam: 12 V / 1 A

When charging from a 24 V lighter socket:
- 2 USB sockets: each 5 V / 2 A
- Dashcam: 24 V / 0.5 A

When discharging the battery:
- 2 USB sockets: each 5 V / 2 A
- Dashcam: 12.8 V / 1 A
